English Instruction Manual Click Here
A GReddy Sirius Control Unit is required for Sirius Vision, Sirius Meter, and Sirius Unify. One Control Unit can up to 3 Sirius Visions and up to 8 Sirius Meters. The Control Unit allows the user to control which parameters are displayed, as well as set and control peak-hold recall and warning settings.
16001721 GReddy Sirius Control Unit - required for use
The award-winning, GReddy Sirius Vision is designed around our advanced thin-film electro luminescent display. The unique clear screen with intense yellow lighting allows the unit to be used as a heads-up display or to be combined with an analog Sirius Meter to overlay additional information. (*sensors sold separately)
16001720 GReddy Sirius Vision - Thin film multi-display
Sirius Meter evolves the classic, easy-to-read, analog GReddy gauge dial with three-dimensional elements to bring vital engine readings to life. The improved form allows the unit to be combined with a Sirius Vision to overlay additional information.
16001730 GReddy Sirius Meter - Turbo Boost
16001731 GReddy Sirius Meter - Water Temp
16001732 GReddy Sirius Meter - Oil Temp
16001733 GReddy Sirius Meter - Oil Press
16001734 GReddy Sirius Meter - Fuel Press
By unifying and overlaying the advanced thin-film electro luminescent display of the Sirius Vision over one of our Sirius Analog Meters, multiple key engine parameters can be viewed clearly and easily from one gauge position.
16001740 GReddy Sirius Vision and Sirius Meter - Turbo Boost
16001741 GReddy Sirius Vision and Sirius Meter - Water Temp
16001742 GReddy Sirius Vision and Sirius Meter - Oil Temp
16001743 GReddy Sirius Vision and Sirius Meter - Oil Press
16001744 GReddy Sirius Vision and Sirius Meter - Fuel Press
*Optional Sensors and Harnesses
16401940 Sirius Boost Pressure Sensor and Harness Set
16401941 Sirius Oil / Fuel Pressure Sensor and Harness Set
16401942 Sirius Oil / Water Temp Sensor and Harness Set
16401935 Sirius Daisy-Chain Extension Harness +1m
16401411 Sirius Temperature Sensor Extension Harness +1m
16401412 Sirius Pressure Sensor Extension Harness +1m
GREDDY SIRIUS FEATURES
- Opening action (start-up)
- Warning mode (alarm)
- Peak hold (recall)
- Individual sensor warning (setting)
- Digital / Bar graph
- 2 Value simultaneous display
- 9 Level dimmer adjustment
- Headlight switch dimmer
- Closing action (shut-down)
Click here to download the instructions, or click on the images to enlarge:
